| SPECIFICATION |
|
|
| TYPE |
ONE NOZZLE(PLUG TYPE)
|
ONE NOZZLE(CONE TYPE) |
| FILLING METHOD |
FULL LOAD CELL WEIGHING TYPE
|
FULL LOAD CELL WEIGHING TYPE |
| FILLING SPEED |
180 CPH (CAN PER HOUR)
|
180 CPH (CAN PER HOUR) |
| WEIGHING RANGE |
0 TO 30kg |
0 TO 30kg |
| WEIGHING ACCURACY |
+ 1/500~1/1000 (FULL SCALE)
|
+ 1/500~1/1000 (FULL SCALE) |
| WEIGHER ACCURACY |
+ 1/3000
|
+ 1/3000 |
| FILLING PRODUCT |
WATER, LUBE OIL, OIL PAINT
WATER PAINT, THINNER,
LIQUID EPOXY, ALCOHOL,
CITRIC ACID, HYDROCHLORIC
ACID, EDIBILITY OIL ETC.
|
WATER, LUBE OIL, OIL PAINT
WATER PAINT, THINNER,?
LIQUID EPOXY, ALCOHOL,
NITRIC ACID, HYDROCHLORIC
ACID, EDIBILITY OIL ETC. |
| FILLING CONTAINER |
STEEL ROUND CAN, STEEL
SQUARE CAN, P.E./P.V.C.
ROUND CAN, SQUARE CAN
|
STEEL ROUND CAN, STEEL
SQUARE CAN, P.E./P.V.C.
ROUND CAN, SQUARE CAN |
| OPERATING AIR |
5~7kg/cm2, NOR 5kg/cm2
|
5~7kg/cm2, NOR 5kg/cm2 |
| AIR CONSUMPTION |
1 LITTER/CYCLE |
1 LITTER/CYCLE |
| OPERATING POWER |
AC 100, 110, 200, 220
230 VOLTAGE 50/60 Hz 1P
|
AC 100, 110, 200, 220
230 VOLTAGE 50/60 Hz 1P |
| POWER CONSUMPTION |
0.5 Kw
|
0.5 Kw |
|
|
